1.Description

The water flow indicator is an integral part of the automatic sprinkler system. The flow of water in the spray pipe network is used to push the blade, and the micro switch is activated to convert the water flow signal into an electrical signal, and is connected with the controller to activate the automatic fire alarm system. It can be used to detect the operation of the automatic sprinkler system and to determine the area where the fire occurred. Suitable for wet, dry, recirculating and closed automatic water spray-foam systems.

Product standard: GB5135.7 "Automatic sprinkler system Part 7: Water flow indicator"

Design Specification: GB50084 "Design Specification for Automatic Sprinkler System"

Acceptance specification: GB50261 "Code for construction and acceptance of automatic sprinkler system"

2. technical parameters

Rated working pressure: 1.2MPa

Sealing test pressure: 2.4MPa

Connection form: saddle type

Alarm flow range: 15L/min~37.5L/min

Switching capacity: AC220V 1A DC24V 0.5A

Environmental conditions: 4 ° C ~ 50 ° C

Wiring method: red line - power line, blue line - signal line

3、Specifications and their appearance and main connection dimensions

• Saddle flow indicator DN50
• Saddle flow indicator DN65
• Saddle flow indicator DN80
• Saddle flow indicator DN100
• Saddle flow indicator DN125
• Saddle flow indicator DN150
• Saddle flow indicator DN200
